Pampering the 'Dragon Lady'

A Crew Chief's guide to looking after the U-2 spyplane

“On 9/11, I told the Chief of the Guards that if my guys were not allowed in when they came, not only would they have to answer to the President of the United States, but I will personally come over there and shit down his neck...”

Retired SMSgt TJ NIZNIK was a U-2 Crew Chief

Everything about the U-2 is unique. The U-2 was designed for a very specific mission, and the designer of the U-2, Kelly Johnson, once said, and I paraphrase, "If you want this aircraft to go high, I cannot design it to military specification". The U-2 is known to save weight. For instance, there are very limited access panels. The requirement of having 2-3 threads of a screw protruding past the nut plate was reduced to being flush with the nut plate. Every pound of weight saved is a foot higher in altitude, and altitude is survivability. There are no self-sealing fuel cells on this jet. The U-2 is a wet wing, meaning the entire wing, from the wing tip to the fuselage, is all fuel. No single point refueling for this jet, nope it's all over the wing refueling. There are 6-8 Crew Chiefs assigned to the aircraft, which is very unlike the rest of the Air Force, where 2-3 are typical.

“The biggest difference between the U-2 and A-10 pilots is that one thought their shit didn't stink, and the other group knew their shit didn't stink.”

The U-2 is a groundcrew nightmare. This is the only aircraft in my career where there is a file system of manufactured blueprints on hand because the tech data may only say remove and replace item X. Well, in any other military standard aircraft the tech data will be step-by-step how to remove and reinstall a part, with pictures and part numbers for consumable items. Not this jet.
